220V/50Hz Voltage Laboratory Fume Hood Chemistry Fume Hoods Enhance Laboratory Efficiency and Safety

Product Specification:

Laboratory Fume Hood is a type of laboratory equipment used to protect personnel and the environment from potentially harmful vapors, gases, and particulate matter. It is an enclosed work area with a ventilated hood that is designed to contain and exhaust hazardous fumes, dust, and particulate matter. The Laboratory Fume Hood features a control system that can be set to either manual or automatic for precise control of the air flow. It is made of high-quality materials such as stainless steel, full steel, PP, and FRP and comes in a white color. It is also equipped with a 1-year warranty for added protection. Chemical fume cupboards, fume hood price, Chemical fume hood lab price, Laboratory Fume Hood are the key words to focus on when considering purchasing this product.

Features:

• Product Name:Chemistry Fume Hood
• Airflow: 100m3/h
• Safety System: Explosion-proof/ Anti-static
• Material: Stainless Steel, Full Steel, Pp, FRP
• Voltage: 220V/50Hz
• Power: 400W
• Keywords: chemistry fume cupboards, chemical fume cupboards, chemistry fume hoods

Technical Parameters:

Applications:

Introducing the SUCLAB HZJFD001 Laboratory Fume Hood, designed for safety and performance in laboratories. Made with the finest materials and designed to be durable and resistant to wear, this fume cupboard is perfect for a wide range of laboratory applications. It is customised to fit your needs and comes with a 1 Year Warranty.

The SUCLAB HZJFD001 features an advanced filter system with both Activated Carbon and HEPA filters for exceptional performance. It is also equipped with an Explosion-proof and Anti-static safety system to protect against any potential hazards.

The SUCLAB HZJFD001 Laboratory Fume Hood is a must-have for any laboratory. It provides a safe and effective way to protect your personnel and laboratory equipment from hazardous chemicals. With its advanced filter system and robust safety system, this laboratory fume cupboard is the perfect choice for any laboratory.

Steel Chemical Biological Chemistry Fume Hood Hood Cupboard Cabinet Descriptions:

-Material, structure...
The left and right side panels of the main body, the front steel plate, the back plate, and the top plate are made of 1.0mm thick steel plate, and 2000W imported from Germany is completely self-contained.
Automatic CNC laser cutting machine blanks the material, and the bending adopts a fully automatic CNC bending machine one-time integrated bending forming, and the surface is made of epoxy resin powder
Automatic spraying and high temperature curing with static current water line.
The inner lining board adopts 5mm thick core anti-fold special board, which has good anti-corrosion and chemical resistance. The deflector is optional, and the fixing parts are made of anti-corrosion polyvinyl chloride material in one piece.
Equipped with fixed windows + 2 moving windows up and down, the glass guide grooves of the moving windows are made of PP material, and the sliding door is light and silent. The handle PP is integrally formed, embedded with 5mm tempered glass, the door opening height is 1450mm, and the door opening height is 1450mm, and the upper and lower transmission device of the sliding door adopts the pulley + wire rope configuration, and the sliding door guide device is made of corrosion-resistant PVC material .
The fixed window frame is made of steel plate and sprayed with epoxy resin, and 5mm thick tempered glass is embedded in the frame.
All the internal connection devices of the connection part are hidden and arranged and anti-corrosion. There are no exposed screws, and the external connection devices are all anti-corrosion.
Learn corroded stainless steel parts and non-metallic materials.
The exhaust outlet adopts a gas collecting hood integrally formed with the top plate, and the air outlet has a circular hole with a diameter of 250mm and is connected by a sleeve to reduce gas turbulence.

-Accessories...
The inner side of the side board can be equipped with an optional waterway (one-time molded PP small cup tank, acid and alkali resistance, corrosion resistance. Single-port copper valve core laboratory special faucet.)
The circuit control panel adopts a liquid crystal display panel (the opening stroke of the damper can be set, and the electric damper can be opened quickly in 6 seconds), 8 buttons (power, setting, confirm, lighting, backup, fan, damper +-key) . Illumination LED white light fast start type, installed on the top of the fume hood, long service life. The socket is equipped with four 10A 220V five-hole multi-function sockets. The line uses Chint 2.5 square copper core wire.
The hinge of the lower cabinet door adopts the "DTC brand" 110-degree straight bending hinge, which has a long service life and is easy to disassemble and assemble.
Other maintenance windows are reserved in the back panel of the lower cabinet to facilitate troubleshooting. 4 holes are reserved on the left and right side panels to facilitate the installation of cork and other facilities.

Specification:

Size(W*D*H)	1200*850*2350 mm	1500*850*2350 mm	1800*850*2350 mm
Exhaust air volume	1200-1800m³/h	1500-2000m³/h	1800-3000m³/h
Air Velocity	0.4-0.8m/s
Noise	≤48dB(A)
Sash	6mm thickness tempered glass
Operation Table Board	Trespa panel / Epoxy resin / Stainless Steel / Ceramics /PP
Lighting equipment	Full Cover Type Three-way Lamp, Lamp Cover with 220v * 20w * 2
Operation panel	Lighting Switch, ON/OFF Switch, Two Sets of 220V/10A Versatile Electric Socket
Ventilation equipment	Selecting rust-resistance, low wasting, low noise and famous fan and special wind tube. Noise can be reduced at about 55 DB .
Accessories	Cock: made by brass, the surface is treated by EPOXY baking paint; Cup slot:acid and alkali resistance, PP water cup
Sink	PP Sink, Epoxy Resin Sink, Stainless Steel Sink
Electric Socket	Multi-functional with splash-proof box and safeguard cover.

Customization:

• Brand Name: SUCLAB
• Model Number: HZJFD001
• Place of Origin: CHINA
• Airflow: 100m³/h
• Noise Level: ≤60dB
• Voltage: 220V/50Hz
• Control System: Manual/Automatic
• Size: Customized

SUCLAB's laboratory fume hoods are designed to provide safe and efficient containment of hazardous fumes generated in a laboratory environment. Their sturdy design is perfect for use in any chemistry fume cupboard, and their competitive fume hood price makes them an ideal choice for any laboratory. With a high airflow of 100m³/h and low noise level of ≤60dB, these fume hoods are a great choice for laboratory safety.

Support and Services:

At ABC Company, we provide technical support and services for Laboratory Fume Hoods. Our technical support team is available to help with any questions or issues you may have. We offer a variety of services, including installation, maintenance, and repair. Our team of highly trained technicians have extensive experience in all types of laboratory fume hoods. We also provide replacement parts and consumables, as well as training for new users. Additionally, we provide remote support when necessary. If you have any questions or need assistance with your laboratory fume hood, please do not hesitate to contact us.

Packing and Shipping:

Packaging and Shipping for Laboratory Fume Hood:

The Laboratory Fume Hood shall be securely packaged in a corrugated cardboard box with bubble wrap lining to prevent damage during shipping. The box must be labeled with the product name, weight, and delivery address.

The Laboratory Fume Hood should be shipped via a reliable carrier, such as UPS, FedEx, DHL, etc. The shipper must provide tracking information to ensure proper delivery.

FAQ:

Q1: What is SUCLAB Laboratory Fume Hood Model Number: HZJFD001?

A1: SUCLAB Laboratory Fume Hood Model Number: HZJFD001 is a laboratory fume hood made by SUCLAB in CHINA.

Q2: What is the purpose of SUCLAB Laboratory Fume Hood Model Number: HZJFD001?

A2: The purpose of SUCLAB Laboratory Fume Hood Model Number: HZJFD001 is to provide a safe environment for various experiments in the laboratory by removing hazardous fumes and gases.

Q3: What are the features of SUCLAB Laboratory Fume Hood Model Number: HZJFD001?

A3: SUCLAB Laboratory Fume Hood Model Number: HZJFD001 features a built-in filtration system, adjustable air flow, and an ergonomic design.

Q4: How do I install SUCLAB Laboratory Fume Hood Model Number: HZJFD001?

A4: To install SUCLAB Laboratory Fume Hood Model Number: HZJFD001, please refer to the user manual or contact the SUCLAB customer service.

Q5: What materials is SUCLAB Laboratory Fume Hood Model Number: HZJFD001 made of?

A5: SUCLAB Laboratory Fume Hood Model Number: HZJFD001 is made of durable, corrosion-resistant materials.
